M8 Sensor Connectors for Industrial Automation
Compact 3/4/5-pin M8 connectors for proximity sensors, inductive sensors and IoT devices in automated production lines
Modern automation increasingly uses miniaturized sensors and IoT edge devices that require connectors smaller than standard M12. Space-constrained mounting positions on conveyor frames, robotic end-effectors and compact machine modules demand ultra-compact waterproof connectors without sacrificing reliability.
WLconnectivity M8 connectors deliver reliable sensor connectivity in a compact form factor roughly 60% smaller than M12. 3/4/5-pin configurations for all common sensor signal types. IP67 waterproof sealing for washdown-capable production lines. Operating temperature -40°C to +85°C for cold storage and heat treatment environments. Available in assembly type (field-installable with front/rear lock panel mount) and molded type (straight and right-angle with pre-assembled PVC/PUR/silicone cables). Custom cable lengths from 0.3m to 30m.
M8 connectors feature gold-plated copper alloy contacts for reliable low-voltage sensor signals. IP67 sealing with silicone O-rings rated for continuous washdown exposure. Current rating up to 4A per pin at 60V — sufficient for all common NPN/PNP proximity sensors and inductive/capacitive sensors. Compact panel cutout reduces mounting space by 60% compared to M12. Compatible with major sensor brands including Sick, IFM, Balluff, Omron and Keyence per IEC 61076-2-104.
Related Solutions
M12 Sensor Connectors
M12 for Industrial Automation
Success Stories
Compact Sensor Network for Packaging Line
Compact Sensor Network for Packaging Line
FAQS
How many specifications of connectors does your company offer?
The product center currently offers 2,929 connector specifications, covering different pitches, pin counts, and categories to meet the needs of various application scenarios.
What pin counts are available for a single-row rubber housing with a 1.00mm pitch？
We offer a full range of white 1.00mm single-row plastic housings from 2Pin to 9Pin, with material codes such as A1002HM-102K0 (2Pin) and A1002HM-109K0 (9Pin).
How to obtain 2D/3D drawings of a product?
You can view the complete set of drawings directly on the corresponding product page, or contact customer service to provide the material code.
What application scenarios are suitable for 1.00mm pitch housings?
How can I find the core parameters of a connector, such as its temperature resistance and protection rating?
All products come with detailed specifications, including operating temperature, IP protection, rated current/voltage, and other parameters, which can be obtained from customer service.
